| AC INPUT |
| Rated Input Voltage (VAC) |
208/220/230/240; L+N+PE |
| Voltage Range (VAC) |
90~280±3(Normal Mode); 170~280±3(UPS Mode) |
| Frequency (Hz) |
50/60(Auto Adaptive) |
| AC OUTPUT |
| Rated Capacity (kW) |
5.5 |
| Surge Power (kVA) |
10 |
| Voltage (VAC) |
208/220/230/240 |
| Power Factor (PF) |
1 |
| Frequency |
50/60Hz±0.1% |
| Switch Time (ms) |
10(Normal Mode)/10(UPS Mode) |
| Wave Form |
Pure Sine Wave |
| Overload Capacity (Battery Mode) |
1min@102%~120%; 10s@>120%Load |
| Max.Efficiency (Battery Mode) |
93.5%@24VDC |
| Parallel Quantity |
NA |
| CHARGER (PV/AC) |
| Solar Charge Type |
MPPT |
| Max PV Input Current / Input Power |
27A/9000W |
| MPPT Range@Operating Voltage (VDC) |
60~450 |
| Max PV Open Circuit Voltage (VDC) |
500 |
| Max PV Charge Current (A) |
160 |
| Max AC Charge Current (A) |
160 |
| Max.Charge Current (PV+AC)(A) |
160 |
| BATTERY |
| Rated Voltage (VDC) |
24 |
| Battery Type |
Lithium and Lead-acid |
| INTERFACE |
| HMI |
LCD |
| Interface |
RS232/RS485/USB |
| Monitoring |
WiFi(Optional) |
| GRNERAL DATA |
| Ingress Protection |
IP21 |
| Operating Temperature |
-10℃ ~60℃ |
| Relative Humidity |
5%~95%(Non-condensing) |
| Storage Temperature |
-15℃ ~60℃ |
| Net Weight (kg) |
8 |
| Gross Weight (kg) |
8.8 |
| Dimensions (W*H*D) |
410*336*130mm |
| Carton Dimensions (W*H*D) |
445*380*180mm |
| QTY/CTN |
1 |
| Max.Operating Altitude |
4000m (Derating above 1000m) |
